Take Winter Head On
By the end of winter, everybody says the same thing: Were just tired of all the snow. But with SuperATVs Plow Pro Snow Plow installed on your Yamaha Viking, youll forget that snow was ever a chore. You can attach and remove the 72 blade using the quick-connect mount in minutes, and the seven adjustable plowing angles make the job even more efficient. Plus, the whole thing bolts on easily. Youll be done plowing in no time.

Built for Punishment
Breaking up snow and ice and pushing it off the road is no easy task. Thats why we use 10-gauge steel for the blade and a 4-gauge advanced steel alloy for the cutting edge. Then we reinforce the whole blade with support ribs. That strength is backed up by shock absorbing springs and a tilt-forward design to protect against surprise impacts. Then the whole thing is powder coated to prevent corrosion.

• 10-gauge steel blade
• 4-gauge leading edge
• Flip-forward design
• Two 4-gauge vertical ribs support high-impact areas
• 10-guage horizontal support reinforces the leading edge

Smooth Adjustment
This winch-operated Yamaha Viking snow plow can be run at any of seven different operating angles ranging from 0 to 30 degrees left or right of center. This lets you move all the snow you want in the space you have. The tilt is also adjustable so you get a perfect angle of attack even with up to 3 of lift. Using the winch to lift the blade is smooth and fast so you dont have to stop for ages every time you want to reposition.

• Seven adjustable plowing angles:
• 0, 10, 20, & 30 left or right of center
• 52 to 65 adjustable attack angle
• Height-adjustable skid shoes

Installation Is Easy!
Attaching the quick-connect mount is a piece of cake and doesnt require any drilling. Just bolt it on, assemble the blade, and youre ready to plow at a moments notice. When youre done plowing, the blade removes easily, and you can leave the mount on all winter longit stays out of the way.

NOTES:

• A winch is required to operate this snow plow.
• At stock height, it is only recommended to lift the plow up to 30 off the ground when running at a 30 angle.

Kit Includes:

• 72 snow plow blade
• Quick-connect snow plow mount
• Snow plow frame

Deluxe Accessory Kit Includes:

• (2) Snow plow side shields
• Deflector and marker kit
• Plow angle actuator kit

WARNING:This product can impact machine operation. Customer and/or user is responsible for ensuring that this product is compatible with their machine as currently configured, properly installed, and understands any impact this product has or might have on the machine’s operation.

California Proposition 65 Warning
WARNING:This product may contain a chemical known to the State of California to cause cancer or birth defects or other reproductive harm.

Features:

• 10-gauge steel blade
• 4-gauge steel leading edge
• 72 wide blade
• 16.25 scoop
• Seven adjustable plowing angles:
• 0, 10, 20, & 30 left or right of center
• 52 to 65 adjustable attack angle accommodates stock and lifted machines up to 3
• Two 4-gauge vertical ribs support high-impact areas
• 10-guage horizontal support reinforces the leading edge
• Height-adjustable skid shoes
• Bolt-on quick-connect mount is easy to install
• Winch-operated frame
• Powder-coated mounting components are weather resistant

VEHICLE FITMENT

• Yamaha Viking : 2014-2021
• Yamaha Viking EPS : 2014-2021
• Yamaha Viking EPS Ranch Edition : 2018-2021
• Yamaha Viking EPS SE : 2015-2021
• Yamaha Viking VI : 2015-2021
• Yamaha Viking VI EPS : 2015-2021
• Yamaha Viking VI EPS Ranch Edition : 2016-2021
• Yamaha Viking VI EPS SE : 2015-2016

NOTE:Machines with more than 3 of lift require our Plow Pro Snow Plow drop bracket: SPB-DB-001

INSTALLATION

Instructions
