The PROXP-20RC-THUNDER5 audio kit is a complete plug and play 5-speaker audio system designed for the Polaris RZR Pro XP platform*. This kit fits all models that have an installed Ride Command system. Building of the capabilities of the Polaris Ride Command system the kit features full plug and play integration to the factory harness while power for the system if provided by the included MUD100.4 4-channel and MUD600-1 monoblock amplifiers.Front audio reproduction is handled by a set of the PROXP-20-FS component speakers. The lower 6 rotationally molded speaker pod is designed to install in a matter of minutes and feature integrated RGB lighting while the 1 soft dome tweeter mounts in the upper dash top factory enclosure. Low end comes from the PROXP-20-SW subwoofer enclosure with its high output 10 subwoofer in a ported enclosure that mounts in the dash on the passenger side of the vehicle. Rear sound is provided by a pair of our MUD65PL speaker cans which feature integrated RGB lighting in a compact design with plug and play connectivity. Connections are made via integrated quick connect, watertight harnesses designed for harshest of riding environments.*Not Compatible with non-Pro XP Model RZRs.

PROXP-20-FSKey Features

• All-Weather Construction with UV Inhibitor
• Custom Fit forDash Panel Panel
• No Cutting or Drilling Required
• 6.5″ Midrange Speaker
• 1.0″ Teteron Soft Dome Tweeter
• 75-Watt RMS Power
• Integrated RGB Lighting
• Fully assembled Out of the Box

MUD100-4Key Features

• Compact Design Enables Installation Anywhere
• Conformal Coated Printed Circuit Board that Resists Moisture
• Fixed Crossovers
• High and Low Level Inputs
• 400-Watts RMS Power

MUD65PLKey Features

• Weather Resistant 6.5″ Speaker Pods
• Fits Bars with Diameters of 1.75″, 1.85″, and 2″
• Internal Crossover Network
• ABS Impact Resistant Grille with UV Inhibitor
• Integrated RGB Lighting
• Optional Remote Control and Wiring Harness Available for Custom Color Creation (MUDLEDC)

MUD600.1Key Features

• High Efficiency Class D Topology
• Compact Design Enables Installation Anywhere
• Conformal Coated Printed Circuit Board that Resists Moisture
• Fixed Crossovers
• High and Low Level Inputs
• 600-Watts RMS Power

PROXP-20-SWKey Features

• 10″ Custom Fit Subwoofer Enclosure
• 400-Watt RMS Power
• High Mount Ported
• MountsBehind Dashboard onPassenger Side
• Quick Installation with Installer Friendly Design
• Fully assembled Out of the Box

Plug and Play Connections

The PROXP-20RC-THUNDER5 includes all the wiring required to connect each component. All wiring is ruggedly designed to endure the harsh environments RZRs often find themselves in. All wires are terminated with the appropriate plug for the component being connected, making installation easy.

VEHICLE FITMENT

• Polaris RZR ProR
• Polaris RZR Pro XP
• Polaris RZRTurbo R
